Phoenix Series LED Floodlight
Key Features:
Phoenix Series Outdoor LED Floodlight For Stadium / Sports Floodlight: The Phoenix stadium floodlight is designed to provide superior lighting solutions for areas requiring strict control of floodlighting and glare, such as residential areas, port facilities, natural parks, and HDTV sports facilities.
The asymmetrical photometric distribution is suitable for 110 x 68 m football fields, one of the largest sizes. With four 18-meter posts, each equipped with 1800W Phoenix lights, your football field will be well-lit from all four corners without tilt-up.
Pipe heat-dissipation and an individual gearbox are key to reducing the aluminum floodlight weight, with the 1800W Phoenix weighing only 26kg. Through careful design, it has an extremely short and compact structure; the 1800W Phoenix is just 777mm long and 305mm high. Due to its low weight and compact structure, the Phoenix is a fantastic solution for both newly-built and retrofit projects, replacing 2000W HID lamps.
If you require a professional outdoor lighting solution for yards, tennis courts, basketball fields, soccer fields, parliament MUGA fields, rugby fields, cricket fields, baseball fields, school playgrounds, ports, ships, stadiums, cranes, or other open areas, we can provide the best solution.
We will provide you with a Free Lighting Calculation and installation guidance.
| LED Type | Osram P8 | Junction Temperature (Tj) | < 75 ℃ (Ta=30 ℃) |
| Driver | Inventronics Driver | Controls System | 0-10V Dimmable & DALI optional |
| Power Efficiency | 1800 W | Options | Up-20KA Surge Protection |
| Luminaire Efficacy | 140 lm/w | Optics | 10°/30°/Asymmetric C/Asymmetric S |
| Luminous Flux | 252,000 lm | Material | Aluminum Housing, A3/A4 Steel bracket, Tempered glass, Polycarbonate Lenses |
| Correlated Color Temperature | 2700K / 3000K / 4000K / 5000K / 5700K / 6500K | Remarks | CE RoHS SAA RCM |
| CRI | Ra 70/80/90 optional | Ingress Protection Code | IP 67 |
| Operating Temperature Range | -40℃ to 50℃ | Mech. impact protection code | IK10 |
| Mains Voltage | 90～305V AC 50-60Hz | Dimensions | L620 * W660 * H370 mm |
| Output Voltage | DC 168 V | Warranty | 5 Years |
| Output Current | 10.75 A | Net Weight | 25 KG |
| Power Efficiency | 95% | Color | Black / White / Grey |
| Total Harmonic Distortion | < 15% |
| LED Type: | Osram P8 | Junction Temperature (Tj): | < 75 ℃ (Ta=30 ℃) |
| Driver: | Inventronics Driver | Controls System: | 0-10V Dimmable & DALI optional |
| Power: | 1200 W | Options: | Up-20KA Surge Protection |
| Luminaire Efficacy: | 140 lm/w | Optics: | 10°/30°/Asymmetric C/Asymmetric S |
| Luminous Flux: | 168,000 lm | Material: | Aluminum Housing, A3/A4 Steel bracket, Tempered glass, Polycarbonate Lenses |
| Correlated Color Temperature: | 2700K / 3000K / 4000K / 5000K / 5700K / 6500K | Remarks: | CE RoHS SAA RCM |
| CRI: | Ra 70/80/90 optional | Ingress protection code: | IP 67 |
| Operating Temperature Range: | -40℃ to 50℃ | Mech. impact protection code: | IK10 |
| Mains Voltage: | 90～305V AC 50-60Hz | Dimensions: | L615 * W480 * H330 mm |
| Output Voltage: | DC 168 V | Warranty: | 5 Years |
| Output Current: | 6.5 A | Net Weight: | 19 KG |
| Power Efficiency: | 95% | Color: | Black / White / Grey |
| Total Harmonic Distortion: | < 15% |
| LED Type: | Osram P8 | Junction Temperature (Tj): | < 75 ℃ (Ta=30 ℃) |
| Driver: | Inventronics Driver | Controls System: | 0-10V Dimmable & DALI optional |
| Power: | 600 W | Options: | Up-20KA Surge Protection |
| Luminaire Efficacy: | 140 lm/w | Optics: | 10°/30°/Asymmetric C/Asymmetric S |
| Luminous Flux: | 84,000 lm | Material: | Aluminum Housing, A3/A4 Steel bracket, Tempered glass, Polycarbonate Lenses |
| Correlated Color Temperature: | 2700K / 3000K / 4000K / 5000K / 5700K / 6500K | Remarks: | CE RoHS SAA RCM |
| CRI: | Ra 70/80/90 optional | Ingress protection code: | IP 67 |
| Operating Temperature Range: | -40℃ to 50℃ | Mech. impact protection code: | IK10 |
| Mains Voltage: | 90～305V AC 50-60Hz | Dimensions: | L580 * W295 * H295 mm |
| Output Voltage: | DC 168 V | Warranty: | 5 Years |
| Output Current: | 3.8 A | Net Weight: | 7.5 KG |
| Power Efficiency: | 95% | Color: | Black / White / Grey |
| Total Harmonic Distortion: | < 15% |
